The hydraulic discharging machine is a mixer or multifunctional auxiliary equipment. Its function is to discharge or separate the high viscosity material
produced by the mixer. In the form of single cylinder and double cylinder type, using torque motor control, he can transfer the high viscosity materials, such
as ink, adhesive and silica gel in the barrel, through the outlet of the bottom of the press disc or the bottom of the material, so as to carry out various forms
of packaging.
The hydraulic discharging machine is composed of a bottom plate, a barrel location, a hydraulic cylinder, a crossbeam, a torque, an electric motor, a gear
pump, a pressing plate, an electric control box, etc. The hydraulic cylinder is arbitrarily adjusted within the range of 0-20mpa. The piston rod can stay at any
position and can work continuously under guarantee and steady pressure; the pressure disc rubber ring is contacted with the container wall in the container
(with a vacuum defoaming device) so that the material can not go back and forth, the material in the container can be discharged into no detention; the lifting
support is lifted from the hydraulic to the top. The position is convenient for the operator to pack, and has the characteristics of simple structure and
convenient operation.
